SBK Isolation Transformer

The SBK isolation transformer is an efficient and reliable power conversion and isolation device, specifically designed for use in scenarios where there are high requirements for power safety, purity, and stability.

It is made of high-quality cold-rolled silicon steel sheets and high-purity copper wires, and can support various input and output voltage specifications, such as 380V to 220V, 220V to 110V, etc. It can well adapt to different power usage environments.

The working principle is based on electromagnetic induction. By achieving electrical isolation between the input and output circuits, it can effectively block the interference caused by the ground loop.

The SBK isolation transformer can also suppress surges and noise in the power grid, thereby providing a safer and more stable power guarantee for the connected devices.

This transformer is widely used in practice, such as:

- Precision instruments, medical equipment, laboratory power supplies;

- Industrial automation control systems, PLCs, servo drives;

- Communication equipment, data centers, security systems;

- Various machine tools, production lines, etc., in scenarios with high requirements for power quality.

What are the functions of the SBK isolation transformer?

The SBK isolation transformer is an industrial-grade isolation power supply device with extremely high precision and strong purification capacity.

The core function is not simply isolation, but to build an independent, pure, and highly stable power island, completely solving the power quality problems in high-end equipment and complex power grid environments.

Through the primary and secondary windings that are physically isolated, the direct electrical connection between the input side (power grid) and the output side (load) is completely cut off.

The design effectively prevents faults such as leakage current from the power grid side and ground potential rise from being transmitted to the load side, providing fundamental safety protection for personnel and equipment.

A single-point grounded high magnetic permeability copper shielding layer is set between the windings of the SBK isolation transformer to efficiently absorb and introduce the ground wire, and its attenuation ability for high-frequency common-mode noise can reach 60-100 dB.

What is the customization process for the SBK isolation transformer?

Yibaling is a professional manufacturer and supplier, to get a customized solutions of this product, we will following the steps below:

1. Confirmation Metrics

The entire customization process begins with the extreme quantification of load characteristics, electromagnetic environment, and performance indicators (such as clearly defining the common-mode attenuation to be ≥ 100 dB @ 1 MHz), and a legally binding "Customization Technical Specification" is formed.

2. Collaborative Design and Simulation Verification

Subsequently, it enters the collaborative design and simulation verification stager, conducting collaborative simulations of electromagnetic, thermal, mechanical, and EMC based on the specification, and crucially locking in the core materials:

For instance, to achieve the ultimate low loss, the iron core is specified to use ultra-thin nanocrystalline strip materials or 27ZH095 grade silicon steel sheets.

To suppress high-frequency loss, the windings use Leeds wire or super-grade oxygen-free copper foil; the insulation system is specified to be a composite of polyimide film and Nomex paper, and is achieved through vacuum pressure impregnation of solvent-free epoxy resin for integrated packaging.

4. Trial Production and Testing

Subsequently, the prototype will be fabricated, and full-condition real-world testing verification must be conducted at the customer's site or simulation laboratory.

Finally, based on the verified scheme, small-scale production will be carried out, and each SBK isolation transformer must pass the full-item factory test designed according to the specification (such as special noise attenuation testing), along with all the core materials  certification report and process records.

The above is the customized process for the SBK isolation transformer. If the customer requires OEM customized services, our company, Zhejiang Yibaling Power Equipment Co., Ltd., can also meet the requirements. Please contact our customer service.
